Hey guys! Today, we're diving into setting up iOpenVPN on Windows Server 2016. Whether you're a seasoned sysadmin or just getting your feet wet, this guide will walk you through the process step-by-step. So, buckle up, and let's get started!

Why iOpenVPN?

Before we jump into the how-to, let's quickly chat about why you might want to use iOpenVPN in the first place. iOpenVPN is a robust and flexible open-source VPN solution. It's super popular because it offers a secure way to connect to your network remotely. Think of it as your personal Batcave entrance – only instead of fighting crime, you're accessing files, applications, and other resources securely. For those managing Windows Server 2016, setting up iOpenVPN allows your users to connect to the server's network from anywhere, ensuring data is encrypted and safe from prying eyes. Plus, it's highly configurable, meaning you can tweak it to fit your exact needs.

Another great reason to choose iOpenVPN is its cross-platform compatibility. Whether your users are on Windows, macOS, Linux, Android, or iOS, they can connect to your iOpenVPN server without any hassle. This makes it an ideal solution for organizations with diverse device environments. The community support for iOpenVPN is also fantastic, with plenty of forums, tutorials, and documentation available to help you troubleshoot any issues you might encounter. Security-wise, iOpenVPN utilizes strong encryption protocols, such as OpenSSL, to protect your data. You can also implement multi-factor authentication for an extra layer of security, ensuring that only authorized users can access your network. In addition, iOpenVPN supports various authentication methods, including username/password, certificates, and RADIUS, giving you flexibility in how you manage user access. All these features combined make iOpenVPN a solid choice for secure remote access on your Windows Server 2016.

Prerequisites

Before we get our hands dirty, make sure you have these prerequisites in place:

• A Windows Server 2016 instance: This should be up and running, and you should have administrative access.
• A static IP address: This will make your life easier. Dynamic IPs can change, which can break your VPN configuration.
• An internet connection: Obviously, you need this to download the necessary software and for users to connect remotely.

Having these prerequisites sorted out will save you a lot of headaches down the road. Ensuring your Windows Server 2016 instance is properly configured and accessible is crucial. A static IP address ensures that your VPN server remains reachable at a consistent address, preventing connection issues for your users. Additionally, verify that your server has a stable and reliable internet connection to provide a seamless VPN experience. It's also a good idea to have a basic understanding of networking concepts, such as IP addressing, routing, and firewalls, as these will come in handy when configuring and troubleshooting your iOpenVPN setup. Remember to keep your server's operating system and security patches up to date to protect against potential vulnerabilities. By taking these preliminary steps, you'll be well-prepared to set up iOpenVPN on your Windows Server 2016.

Step-by-Step Installation

Alright, let's dive into the nitty-gritty. Follow these steps to get iOpenVPN up and running:

1. Download iOpenVPN

Head over to the official iOpenVPN website and download the Windows installer. Make sure you grab the correct version for your server architecture (32-bit or 64-bit). For Windows Server 2016, you'll most likely need the 64-bit version. Once the download is complete, save the installer to a location on your server where you can easily access it.

2. Install iOpenVPN

Run the installer with administrative privileges. You know the drill – right-click and select "Run as administrator." Follow the prompts, but pay attention to these key points:

• Components: Make sure to select the "OpenVPN Service" and "Easy RSA" components. These are essential for running the VPN server and generating the necessary certificates.
• Installation Directory: You can leave this as the default, but make a note of it. You'll need to find the easy-rsa folder later.

During the installation process, the installer will copy the required files and set up the iOpenVPN service. It will also create the necessary registry entries and configure the firewall to allow iOpenVPN traffic. By selecting the "OpenVPN Service" component, you ensure that the VPN server runs as a background service, providing continuous connectivity. The "Easy RSA" component is crucial for generating and managing the SSL certificates that are used to secure the VPN connection. Without these certificates, your VPN connection would be vulnerable to eavesdropping and man-in-the-middle attacks. Therefore, it's important to make sure both components are selected during the installation. Once the installation is complete, you'll have a fully functional iOpenVPN server ready for configuration.

3. Configure Easy RSA

Easy RSA is a command-line tool for managing the certificates used by iOpenVPN. Here’s how to configure it:

1. Open a Command Prompt as Administrator: You'll need elevated privileges to run these commands.

2. Navigate to the Easy RSA Directory: Use the cd command to navigate to the easy-rsa folder inside your iOpenVPN installation directory. For example:

   cd C:\Program Files\OpenVPN\easy-rsa


3. Initialize the PKI: Run the following command to initialize the Public Key Infrastructure (PKI):

   .\[init-pki.ps1](http://init-pki.ps1)


   This sets up the directory structure for storing certificates and keys.

4. Build the Certificate Authority (CA): Run this command to create the CA certificate:

   .\[build-ca.ps1](http://build-ca.ps1)


   You'll be prompted for some information, like the country, organization, and common name. Fill these in as appropriate. The common name is usually the name of your organization or VPN server.

Configuring Easy RSA correctly is essential for the security of your iOpenVPN server. The PKI (Public Key Infrastructure) provides the foundation for generating and managing the certificates and keys that are used to encrypt the VPN traffic. Initializing the PKI sets up the necessary directory structure for storing these files, ensuring that they are organized and accessible. Building the Certificate Authority (CA) creates the root certificate that is used to sign all other certificates, establishing a chain of trust. When you run the build-ca.ps1 script, you'll be prompted to enter information about your organization, such as the country, state, city, and organization name. This information is included in the CA certificate and helps to identify the certificate's owner. The common name is typically the name of your organization or VPN server and should be descriptive and easily recognizable. Once you've completed these steps, you'll have a CA certificate that you can use to issue certificates for your iOpenVPN server and clients. This ensures that all VPN connections are authenticated and encrypted, protecting your data from unauthorized access.

4. Generate Server Certificate and Key

Now, let’s create the server certificate and key:

.\[build-server-full.ps1](http://build-server-full.ps1) server

You’ll be prompted for the common name again. Just enter "server" (or whatever you want to call your server). This script will generate the server certificate and private key, which are crucial for the iOpenVPN server to operate securely. After running the script, you'll find the server certificate (server.crt) and private key (server.key) in the easy-rsa/pki/issued/ and easy-rsa/pki/private/ directories, respectively. These files are used by the iOpenVPN server to authenticate itself to clients and encrypt the VPN traffic. It's important to keep the private key secure, as anyone who has access to it can impersonate your server and intercept VPN traffic. Therefore, you should protect the private key with appropriate file permissions and consider storing it on a hardware security module (HSM) for added security. Generating the server certificate and key is a critical step in setting up iOpenVPN, as it ensures that all VPN connections are encrypted and authenticated, protecting your data from unauthorized access.

5. Generate Client Certificates and Keys

For each user who needs to connect to the VPN, you'll need to generate a client certificate and key. Run this command for each user:

.\[build-client-full.ps1](http://build-client-full.ps1) client1

Replace client1 with the username or a descriptive name for the client. This will generate a certificate and key for that user. After running the script, you'll find the client certificate (client1.crt) and private key (client1.key) in the easy-rsa/pki/issued/ and easy-rsa/pki/private/ directories, respectively. These files are used by the iOpenVPN client to authenticate itself to the server and encrypt the VPN traffic. It's important to distribute the client certificate and key securely to the user, as anyone who has access to them can connect to your VPN server. You should also consider implementing multi-factor authentication for added security, which requires users to provide additional credentials, such as a one-time password, in addition to the certificate and key. Generating client certificates and keys is a fundamental step in setting up iOpenVPN, as it allows you to control who can access your VPN server and ensures that all VPN connections are encrypted and authenticated, protecting your data from unauthorized access.

6. Create the iOpenVPN Server Configuration File

Now, we need to create the iOpenVPN server configuration file. This file tells iOpenVPN how to behave. Create a new text file named server.ovpn in the iOpenVPN configuration directory (usually C:\Program Files\OpenVPN\config). Paste the following configuration into the file:

port 1194
proto udp
dev tun
ca easy-rsa/pki/ca.crt
cert easy-rsa/pki/issued/server.crt
key easy-rsa/pki/private/server.key  # This file should be kept secret
dh easy-rsa/pki/dh.pem
server 10.8.0.0 255.255.255.0
ifconfig-pool-persist ipp.txt
push "redirect-gateway def1 bypass-dhcp"
push "dhcp-option DNS 8.8.8.8"
push "dhcp-option DNS 8.8.4.4"
keepalive 10 120
comp-lzo
persist-key
persist-tun
status openvpn-status.log
log-append  openvpn.log
verb 3
tls-server
tls-version-min 1.2
tls-cipher TLS-ECDHE-RSA-WITH-AES-128-GCM-SHA256

Important Notes: Adjust the paths to the ca.crt, server.crt, and server.key files to match your actual directory structure. The server directive specifies the IP address range for the VPN. Creating the iOpenVPN server configuration file is a crucial step in setting up your VPN server. This file contains all the settings that control how iOpenVPN operates, including the port it listens on, the protocol it uses, the encryption algorithms it employs, and the IP address range it assigns to clients. The port directive specifies the port number that the iOpenVPN server will listen on for incoming connections. The proto directive specifies the transport protocol to use, which can be either UDP or TCP. The dev directive specifies the type of virtual network device to create, which can be either a TUN or TAP device. The ca, cert, and key directives specify the paths to the CA certificate, server certificate, and server private key, respectively. The dh directive specifies the path to the Diffie-Hellman parameter file, which is used for key exchange. The server directive specifies the IP address range to use for the VPN, and the push directives specify the DNS servers to use for clients and whether to redirect all traffic through the VPN. The keepalive directive specifies the interval at which to send keep-alive packets to clients to detect connection failures. The comp-lzo directive enables LZO compression to reduce bandwidth usage. The persist-key and persist-tun directives prevent the server from dropping the key and tunnel after a restart. The status directive specifies the file to write the iOpenVPN status to, and the log-append directive specifies the file to append log messages to. The verb directive specifies the level of verbosity for the iOpenVPN log. Ensuring that this file is configured correctly is critical for the proper functioning and security of your VPN server.

7. Generate Diffie-Hellman Parameters

Generate the Diffie-Hellman parameters to enhance key exchange security. Run this command:

.\[gen-dh.ps1](http://gen-dh.ps1)

This will create a dh.pem file in the easy-rsa/pki/ directory. Generating Diffie-Hellman (DH) parameters is a crucial step in enhancing the security of your iOpenVPN server. DH parameters are used during the key exchange process to establish a shared secret between the server and the client, which is then used to encrypt the VPN traffic. By generating your own DH parameters, you ensure that the key exchange process is secure and resistant to certain types of attacks. The gen-dh.ps1 script generates a dh.pem file, which contains the DH parameters. This file is then referenced in the iOpenVPN server configuration file (server.ovpn) using the dh directive. When the iOpenVPN server starts, it loads the DH parameters from the dh.pem file and uses them during the key exchange process. Generating strong DH parameters is essential for ensuring the confidentiality and integrity of your VPN traffic.

8. Copy Files to the iOpenVPN Configuration Directory

Copy the following files from the easy-rsa/pki directory to the iOpenVPN configuration directory (C:\Program Files\OpenVPN\config):

• ca.crt
• dh.pem

Also, copy the server.crt and server.key files from easy-rsa/pki/issued/ and easy-rsa/pki/private/ respectively to the same iOpenVPN configuration directory. Copying the necessary files to the iOpenVPN configuration directory is a critical step in setting up your VPN server. The ca.crt file contains the certificate of the Certificate Authority (CA), which is used to verify the authenticity of the server and client certificates. The dh.pem file contains the Diffie-Hellman (DH) parameters, which are used for key exchange. The server.crt file contains the server's certificate, which is used to identify the server to clients. The server.key file contains the server's private key, which is used to encrypt and decrypt VPN traffic. By copying these files to the iOpenVPN configuration directory, you ensure that the iOpenVPN server has access to the necessary certificates and keys to operate securely. It's important to keep the server.key file secure, as anyone who has access to it can impersonate your server and intercept VPN traffic. Therefore, you should protect the private key with appropriate file permissions and consider storing it on a hardware security module (HSM) for added security.

9. Start the iOpenVPN Service

Open the Services application (search for "Services" in the Start Menu) and find the "OpenVPNService." Right-click it and select "Start." If it’s already running, restart it to apply the changes. Starting the iOpenVPN service is the final step in setting up your VPN server. Once the service is started, it will listen for incoming connections on the configured port (default is 1194) and establish VPN tunnels with clients. If the service is already running, restarting it will apply any changes you've made to the configuration file. You can monitor the iOpenVPN log file (openvpn.log) to check for any errors or warnings. If the service fails to start, check the log file for clues about what went wrong. Common issues include incorrect file paths, invalid configuration settings, and firewall restrictions. Ensuring that the iOpenVPN service is running is essential for providing secure remote access to your network.

10. Configure the Windows Firewall

Make sure that the Windows Firewall allows traffic on the port you've configured (default is 1194). You might need to create a new inbound rule to allow UDP traffic on this port. Configuring the Windows Firewall is a critical step in ensuring that your iOpenVPN server is accessible to clients. By default, the Windows Firewall blocks all incoming traffic, so you need to create a new inbound rule to allow traffic on the port that iOpenVPN is listening on (default is 1194). You can create this rule using the Windows Firewall with Advanced Security console. When creating the rule, specify that it should allow UDP traffic on port 1194. You can also restrict the rule to only allow traffic from specific IP addresses or subnets, which can enhance the security of your VPN server. Ensuring that the Windows Firewall is properly configured is essential for allowing clients to connect to your iOpenVPN server.

Client Configuration

Now that the server is set up, let's configure the client:

1. Install the iOpenVPN Client

Download and install the iOpenVPN client on the user's machine. This is available on the iOpenVPN website.

2. Create the Client Configuration File

Create a .ovpn file for the client. This file tells the client how to connect to the server. Here’s an example:

client
dev tun
proto udp
remote your_server_ip 1194
resolv-retry infinite
nobind
persist-key
persist-tun
ca ca.crt
cert client1.crt
key client1.key
remote-cert-tls server
comp-lzo
verb 3
tls-version-min 1.2
tls-cipher TLS-ECDHE-RSA-WITH-AES-128-GCM-SHA256

Replace your_server_ip with the public IP address of your server. Copy the ca.crt, client1.crt, and client1.key files to the same directory as the .ovpn file.

3. Import the Configuration File

Import the .ovpn file into the iOpenVPN client. The client will then use this configuration to connect to the server.

Testing the Connection

Finally, test the connection. Start the iOpenVPN client and connect to the server. If everything is configured correctly, you should be able to access resources on the server's network. Testing the connection is the final step in setting up your iOpenVPN server and client. Once the client is connected to the server, you should be able to access resources on the server's network, such as files, printers, and applications. You can also verify that your traffic is being routed through the VPN by checking your IP address. If your IP address matches the IP address of your iOpenVPN server, then your traffic is being routed through the VPN. If you encounter any issues during the connection process, check the iOpenVPN log files on both the server and the client for clues about what went wrong. Common issues include incorrect file paths, invalid configuration settings, and firewall restrictions. Ensuring that the connection is working properly is essential for providing secure remote access to your network.

Conclusion

And there you have it! Setting up iOpenVPN on Windows Server 2016 might seem daunting at first, but with these steps, you should be able to get it up and running smoothly. Happy networking, folks! Remember that keeping your VPN secure requires regular maintenance and updates. Always stay informed about the latest security threats and best practices for iOpenVPN.
